Telehandler Truss Booms

Truss Boom for Telehandlers - The telescopic handler or telehandler is a generally utilized machine in agricultural and industrial applications. This particular equipment is similar in look to a forklift and even functions in a similar way, even if telehandlers are much more like a crane than forklift. It has a telescopic boom which can extend forward and upward from the vehicle. The boom has the capability to fit one of various attachments like pallet forks, a bucket, a lift table or muck grab.

The most popular telehandler attachments are pallet tines. The telehandler is used in order to transport items in places where the loads cannot be transported by a standard forklift. Telehandlers are specially helpful for placing loads on rooftops for instance, or for removing palletized cargo from with a trailer. Many of the tasks that a telehandler could accomplish would otherwise require a crane and this particular machine can be costly, not always time efficient and impractical.

The boom acts as a lever, extending and raising while bearing a load. Though there are rear counterweights, this might cause the telehandler to become more unbalanced. Therefore, the greatest advantage of the telehandler is likewise its greatest limitation. As the working radius increases, the lifting capacity lessens. The working radius is defined as the distance between the front of the wheels and the center of the load.

Like for example, a telehandler with a 5000 lb capacity with the boom retracted can safely lift as little as 400 lb when it is completely extended at a low boom angle. The equivalent machine that has a 5000 lb lift capacity and the boom retracted could support as much as 10,000 lb with the boom raised to 70 degrees. The operator has a load chart in order to help determine whether a specific lifting task could be done in a safe and efficient manner. This particular chart takes into consideration the weight, height and the boom angle.

To be able to monitor the telehandler, they come equipped with a computer that utilizes sensors. These sensors work to warn the operator, with some being able to cut controls to certain inputs if the limits of the vehicle are exceeded. Several telehandler models are likewise outfitted along with front outriggers that are referred to as mobile cranes. These really extend the lifting capacity of the machinery while it is stationary.


Click to Download the pdf
