Carriage for Forklift - There are 4 sizings of hook type tine carriages rated by the blade carriage lifting capacity. Hook type blade carriages have been uniform.
The carriage bar spacing for Class 1 is approximately 13 inches and the Class 1 carriage is rated to carry cargo up to 2000lbs. The Class 2 carriage is rated to carry loads up to 5,500lbs with carriage bar spacing of 16 inches. Class III carriages are rated for cargo up to 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing for this capacity is twenty five inches.
Pin mounted blades vary by the amount of offset between the tine and the blade eye. Some manufacturers would differ the carriages for pin type tines. Carriage capacity will be determined by the carriage pin size and by the blade size.
